Belden 29530C 2/0 AWG 3 Conductor 19×12 Stranding 600V Variable Frequency Drives Cable

Belden 29530C 2/0 AWG 3 Conductor Stranding Variable Frequency Drives ✓ Meilleur prix garanti ✓ 100% Satisfaction garantie ► Commandez dès maintenant

[pdf] [/pdf]
Belden 29530C 2/0 AWG 3 Conductor 19×12 Stranding 600V Variable Frequency Drives Cable
:
Belden Basics VFD, 3 Conductor 2/0AWG (19×12) Bare Cuivre XLPE Insulation M4 Color Code + 5AWG Symmetrical Segmented Ground (3 of 10AWG) Bare Copper Stranded in Continuous Contact with Overall Dual Copper Tape Helically Applied Shield, Noir charbon PVC Outer Jacket, 600/1000V TC-ER 90C Dry/Wet 1000V CSA AWM I/II A/B SUN RES DIR BUR Oil Resistant.
Insulation:
Element: Conductor(s):-
Material: XLPO – Crosslink Polyolefin
Nom. Thickness: 0.057 in (1.4 mm)
Nom. Insulation Diameter: 0.516 in (13.1 mm)
Outer Shield:
• Shield Type: Helical Tape • Material: Bare Copper (BC) • Coverage: 100%
Outer Jacket:
• Material: PVC – Polyvinyl Chlori
